Security appliance - with 1 year FortiCare Premium Support + 1 year FortiGuard Enterprise Protection - 400GbE, 200GbE, 50GbE, 10GbE - front to back airflow - 3U - rack-mountable
| Main Specifications | |
|---|---|
| Product Description | Fortinet FortiGate 3801G - security appliance - with 1 year FortiCare Premium Support + 1 year FortiGuard Enterprise Protection |
| Device Type | Security appliance |
| Bundled Services | 1 year FortiCare Premium Support + 1 year FortiGuard Enterprise Protection |
| Form Factor | Front to back airflow rack-mountable - 3U |
| Processor | Fortinet FortiASIC CP10/NP7 |
| Hard Drive | 1.92 TB x 2 |
| Data Link Protocol | 400 Gigabit Ethernet, 200 Gigabit Ethernet, 50 Gigabit Ethernet, 10 Gigabit Ethernet, Gigabit Ethernet |
| Performance | Firewall throughput (1518-byte UDP): 795 Gbps ¦ Firewall throughput (512-byte UDP): 793 Gbps ¦ Firewall throughput (64-byte UDP): 453 Gbps ¦ IPS throughput (enterprise traffic mix): 250 Gbps ¦ NGFW throughput (enterprise traffic mix): 210 Gbps ¦ Threat protection throughput (enterprise traffic mix): 200 Gbps ¦ Firewall latency (64-byte UDP): 3.53µs ¦ VPN throughput (SSL): 27 Gbps ¦ SSL inspection throughput: 120 Gbps ¦ Application control (AVC) throughput: 315 Gbps |
| Capacity | New sessions per second: 1100000 ¦ Concurrent TCP sessions: 200000000 ¦ Firewall policies: 400000 ¦ Gateway to gateway IPSec VPN Tunnels: 400000 ¦ Client to gateway IPSec VPN tunnels: 200000 ¦ Concurrent SSL VPN users: 30000 ¦ Number of FortiAP devices: 8192 ¦ Number of FortiAP devices (tunnel): 4096 ¦ Maximum number of FortiSwitch: 300 ¦ Maximum number of FortiTokens: 20000 ¦ Virtual domains: 10 ¦ Maximum virtual domains: 500 ¦ Firewall policies: 400000 |
| Included Accessories | 2 x SR 10Gbps SFP+ transceivers, 6 rubber feet |
| Power | AC 200-240 V (50/60 Hz) |
| Power Redundancy | Yes |
| Dimensions (WxDxH) | 17.2 in x 26.1 in x 5.2 in |
| Weight | 71.65 lbs |
| General | |
| Device Type | Security appliance |
| Bundled Services | 1 year FortiCare Premium Support + 1 year FortiGuard Enterprise Protection |
| Height (Rack Units) | 3U |
| Built-in Devices | LCD Customer Display, 3 x fans |
| Width | 17.2 in |
| Depth | 26.1 in |
| Height | 5.2 in |
| Weight | 71.65 lbs |
| Expansion / Connectivity | |
| Interfaces | 4 x 400Gb Ethernet - QSFP-DD ¦ 6 x 200Gb Ethernet - QSFP56 ¦ 18 x 50Gb Ethernet - SFP56 ¦ 2 x 10Gb Ethernet (management) - RJ-45 ¦ 1 x console ¦ 1 x USB |
| Miscellaneous | |
| Included Accessories | 2 x SR 10Gbps SFP+ transceivers, 6 rubber feet |
| Cables Included | 1 x network cable ¦ 1 x console cable |
| Compliant Standards | IPv6, USGv6 |
| Networking | |
| Form Factor | Rack-mountable |
| Airflow Direction | Front to back airflow |
| Connectivity Technology | Wired |
| Data Link Protocol | 400 Gigabit Ethernet, 200 Gigabit Ethernet, 50 Gigabit Ethernet, 10 Gigabit Ethernet, Gigabit Ethernet |
| Network / Transport Protocol | IPSec, TCP/IP, UDP/IP |
| Remote Management Protocol | HTTP, HTTPS |
| Performance | Firewall throughput (1518-byte UDP): 795 Gbps ¦ Firewall throughput (512-byte UDP): 793 Gbps ¦ Firewall throughput (64-byte UDP): 453 Gbps ¦ IPS throughput (enterprise traffic mix): 250 Gbps ¦ NGFW throughput (enterprise traffic mix): 210 Gbps ¦ Threat protection throughput (enterprise traffic mix): 200 Gbps ¦ Firewall latency (64-byte UDP): 3.53µs ¦ VPN throughput (SSL): 27 Gbps ¦ SSL inspection throughput: 120 Gbps ¦ Application control (AVC) throughput: 315 Gbps |
| Capacity | New sessions per second: 1100000 ¦ Concurrent TCP sessions: 200000000 ¦ Firewall policies: 400000 ¦ Gateway to gateway IPSec VPN Tunnels: 400000 ¦ Client to gateway IPSec VPN tunnels: 200000 ¦ Concurrent SSL VPN users: 30000 ¦ Number of FortiAP devices: 8192 ¦ Number of FortiAP devices (tunnel): 4096 ¦ Maximum number of FortiSwitch: 300 ¦ Maximum number of FortiTokens: 20000 ¦ Virtual domains: 10 ¦ Maximum virtual domains: 500 ¦ Firewall policies: 400000 |
| Status Indicators | Status, alarm, HA, power |
| Features | Trusted Platform Module (TPM), signed firmware, firewall protection, SaaS protection, zero-day malware detection, web threat protection, anti-malware protection |
| Encryption Algorithm | SSL, TLS 1.3, 256-bit AES, 256-bit SHA |
| Power | |
| Power Device | Internal power supply - hot-plug |
| Installed Qty | 4 |
| Power Redundancy | Yes |
| Voltage Required | AC 200-240 V (50/60 Hz) |
| Power Consumption Operational | 1496 Watt |
| 80 PLUS Certification | 80 PLUS Platinum |
| Software / System Requirements | |
| OS Provided | FortiOS |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 20 - 90% (non-condensing) |
| Processor / Memory / Storage | |
| Processors Installed | Fortinet FortiASIC CP10/NP7 |
| Hard Drive | SSD 1.92 TB x 2 |
