Opengear OM2224-24E - console server - with smart out-of-band management - cloud-managed - TAA Compliant
Device Type
Console server
Form Factor
Rack-mountable - 1U
Localization
Global
Processor
1 x AMD GX-412TC 1.4 GHz
RAM
8 GB
Flash Memory
16 MB
Hard Drive
64 GB x 1 - SATA 6Gb/s
Ports Qty
24
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet, RS-232
Mobile Broadband Access
Yes
Generation
4G
Cellular Protocol
LTE Advanced Pro Cat 12
Included Accessories
Rack mount kit, 2 power cords, 2 x cellular antennas, cellular antenna extender
Power
AC 100-240 V (50/60 Hz)
TAA Compliant
Yes
Dimensions (WxDxH)
17.3 in x 10.2 in x 1.8 in
Weight
7.72 lbs
Manufacturer Warranty
5-year warranty
General
Device Type
Console server
Height (Rack Units)
1U
Built-in Devices
24-port switch
Width
17.3 in
Depth
10.2 in
Height
1.8 in
Weight
7.72 lbs
Localization
Global
Expansion / Connectivity
Expansion Slots
2 (total) / 2 (free) x SIM card
Interfaces
24 x RS-232 - RJ-45 ¦ 24 x 1000Base-T - RJ-45 ¦ 1 x console - micro-USB ¦ 1 x console - RJ-45 ¦ 2 x 1000Base-X - SFP (mini-GBIC) ¦ 8 x management (USB) - Type A ¦ 2 x USB 3.0 - Type A
Manufacturer Warranty
Service & Support
Limited warranty - hardware replacement - 5 years
Miscellaneous
Included Accessories
Rack mount kit, 2 power cords, 2 x cellular antennas, cellular antenna extender
Cables Included
1 x CAT5 cable - 5 ft ¦ 1 x DB-9 to RJ-45 adapter
MTBF
100,000 hours
Compliant Standards
EN 55032:2015 Class A, EN 61000-4-2, EN 61000-4-3:2006+A1:2006+A2:2010, EN 61000-4-4:2007, EN 61000-4-5:2014, EN 61000-4-6:2008, EN 61000-4-8:2009, EN 61000-4-11:2010, EN 61000-4-28:2010, EN 61000-3-2:2014, EN 61000-3-3:2013, IEC60950-1:2005, Second edition + Am1:2009 + Am2:2013, EN 60950-1:2006+A11:2009+A1:2010+A12:2011+A2:2013
